C. Tempered Glass Siding Sash: When closed, the cabinet sash isolates the air within and protects interior work items from inadvertent external contact.
D. Spillage Tray: A black polypropylene spillage tray is removable for easy cleaning.
E. ECOair™ Touchpad Control Panel (shown): Security access color touch screen controller for set point, monitoring parameters and all operational and safety features.
F. Steel Support Frame: Chemical resistant coating.
G. Electrostatic Pre-Filter: 95.5% effective pre-filter, accessible from inside the work area to contain the release of any trapped particulates.
H. Pass-Thru Ports: For routing electrical cords and instrumentation leads as required.
I. Dynamic Filtration Chamber: Prevents any possible leakage of contaminated air by pressurizing the fan plenum (positive air) and depressurizing the filter compartment (negative air).
J. Stand: Optional stand.
K. Safety Filter: Optional carbon or HEPA/ULPA safety filter adds additional protection.
L. Track and Wheel system: Permits the filter wheels to glide into place on tracks before clamping tightly to the filter gasket; prevents damage during installation and assures filter integrity.
M. Modular Utility Package (Optional).
N. Ergonomic Arm Rest: An ergonomic arm rest improves user comfort and productivity.
Smooth Sash Operation: The chain drive sash mechanism is quieter and smoother to operate than conventional counterbalanced design.
Sash Options: Manual sliding sash, standard. Optional motorized sliding sash or manual hinged sash are available; see accessories.
Power Supply: Operates on standard 120V, 60Hz, 1 phase power; other voltages available upon request.
Electronic Gas Detection System: Increases safety, provides four methods for filter monitoring and gas detection.
