Purair RX Ductless Balance Enclosures
- High efficiency ebm-papst EC blower.
- Energy savings LED lighting.
- Protects the operator from powder and particle hazards.
- Improved filter clamping eliminates bypass leakage.
- Exhaust canopy allows for thimble ducting to the facility exhaust system.
- Filter blockage alarm.
- Complies with USP 800 USP 795 guidelines.
Description
Model Specifications
Internal Height: 23.6″ | 600 mm
External Width: 24″ | 610 mm
External Depth: 27″ | 676 mm
External Height: 35″ | 889 mm
Shipping Width: 40″ | 1016 mm
Shipping Depth: 40″ | 1016 mm
Net Weight: 72 lbs | 33 kg
Shipping Weight: 150 lbs | 68 kg
Cabinet Style: Standard
Construction: Epoxy-coated Steel
OSHA: OSHA Standard -29 CRF, Safety and Health Regulations for General Industry, 1910.1450: Occupational exposure to hazardous chemicals in laboratories. Part B, definition, laboratory type hood. This product may assist you with compliance or as part of your chemical hygiene plan. Please consult your Safety Officer and/or Industrial Hygienist.
Environmental: ISO 14001 : 2015; ENERGY STAR® Partner
Quality: ISO 9001 : 2015
Autocal Control Panel*: AUTOCAL
Base Cabinet, Fixed (Metal): CART-MCC-25
Base Cabinet, Fixed (Polypropylene): CART-SSC-25
Base Stand, Mobile, with Casters: CART-25
Dwyer Air Flow Meter: DWYER
FSA Control Panel*: FSA
FSA/Autocal Control Panel*: ADV-P
Fire Safety Cabinet Base: CART-FSC-25
Monitair Controller: MON-P
SafeSwitch HEPA Filter Shutter System: ASTS-030-SS
Spill Tray (Polypropylene): TRAY-P5-24
Spill Tray (Stainless Steel): TRAY-P5-24-SS
* Factory installed; specify when ordering
Airflow: Vertical
Airflow Direction: Upflow
Face Velocity: 100
Main Filter: HEPA (ULPA optional)
Carbon Filter: (Optional) Activated Carbon
Biological Filter: (Optional) HEPA (ULPA optional)
Electrical Voltage: 120V, 60Hz
NEMA Plug: 5-15P
Control: Fan Manual On Off
Monitoring Options:
/ / standard
Technical Info
| Model | Width | Depth | Height |
|---|---|---|---|
| P5-24-XT (RX) -A | 24" | 610 mm | 27" | 676 mm | 35" | 889 mm |
| P5-36-XT (RX) -A | 36" | 914 mm | 27" | 676 mm | 35" | 889 mm |
| P5-48-XTS (RX) -A | 48" | 1219 mm | 24" | 610 mm | 35" | 889 mm |
| P5-48-XT (RX) -A | 48" | 1219 mm | 27" | 676 mm | 35" | 889 mm |
| P5-36-XTS (RX) -A | 36" | 914 mm | 24" | 610 mm | 35" | 889 mm |
| P5-24-XTS (RX) -A | 24" | 610 mm | 24" | 610 mm | 35" | 889 mm |
| Model | Width | Depth | Height |
|---|---|---|---|
| P5-24-XT (RX) -A | - | - | 23.6" | 600 mm |
| P5-36-XT (RX) -A | - | - | 23.6" | 600 mm |
| P5-48-XTS (RX) -A | - | - | 23.6" | 600 mm |
| P5-48-XT (RX) -A | - | - | 23.6" | 600 mm |
| P5-36-XTS (RX) -A | - | - | 23.6" | 600 mm |
| P5-24-XTS (RX) -A | - | - | 23.6" | 600 mm |
| Formula | Description |
|---|---|
| GP Plus! | The most widely used filter in the range, primarily for solvent, organic and alcohol removal. |
| ACI Plus!/SUL | Designed to neutralize volatile inorganic acid vapors. |
| ACR | Iodine and methyl iodide vapors; It is frequently used for iodination reactions with lower level radioactive iodine. |
| ACM | Mercury vapor |
| AMM | Removes vapors from dilute ammonia solutions and to remove low molecular weight amines. |
| FOR | Designed to oxidize formaldehyde and glutaraldehyde fumes; It is widely used in hospital pathology laboratories. |
| HEPA/ULPA | Powders and particulates. |
Using innovative filtration technology, the Purair RX creates a safe work environment over the widest range of applications in the industry.
Balance Enclosures \ Compounding \ Powder Mixing \ Powder Weighing
